| Referencia | Unidades por caja | Medida | A | B | C | D | E | F | DN | Ø | Peso |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 052013 | 30 | 20-1/2" | 110 | 92 | 97.8 | 34 | 17.8 | 52 | 15 | ½” | 145 |
| 052014 | 20 | 25-3/4" | 126.6 | 92 | 105.5 | 42 | 16.8 | 63 | 20 | ¾” | 200 |
| 052015 | 15 | 32-1" | 159 | 113.7 | 126.8 | 46.5 | 26.9 | 73 | 25 | 1” | 275 |
| 052016 | 10 | 40-1 1/4" | 174.6 | 113.7 | 134 | 55.6 | 24 | 84 | 32 | 1 ¼” | 445 |
| 052017 | 10 | 50-1 1/2" | 200 | 141.8 | 158.8 | 64.2 | 27 | 96.6 | 40 | 1 ½” | 715 |
| 052018 | 5 | 63-2" | 225.4 | 141.8 | 172 | 72 | 29.5 | 110 | 50 | 2” | 1035 |
